KNL-16 DXpedition Report (1-5 December 2025).

On the 1st of December, we arrived on site around mid-day.

Field conditions were favourable this year, with no mud or heavy ploughing as encountered on previous expeditions. This allowed for a smooth installation of the first set of receiving antennas. Deployed were the 300° North American Beverage, the reversible ARG/JAP Beverage, and the African BOG (Beverage On Ground).



Other participants deployed the following antennas: Vertical 9 metre with balun, LA-1 van Dijken loop, 1090Mhz antenna, Active L-Band 1525-1660 antenna, Vertical 7,- m, T2FD or13 MHz and a Sony AN1.



On the following day, the Far East / Colombia reversible Beverage antenna was installed. With this final deployment completed, the receiving site was fully operational.

Initial monitoring was severely affected by wideband QRM. Extensive troubleshooting followed: all feedlines and terminations were checked, laptops and other potential noise sources were powered down, and a systematic RFI hunt was carried out using a portable receiver both indoors and in the field. Persistent QRM was present throughout — until the small house was investigated. After switching off the halogen lighting, the noise floor dropped very dramatically, resulting in a largely clean MW band.



It was later noted that the Deepelec DP-666 is not suitable for MW-QRM hunting, as its display generates noise, potentially leading to false conclusions during RFI investigations.



Consequently, the first night produced little of interest beyond the usual power stations.



Geomagnetic conditions were poor, and propagation forecasts suggested a preference for southern paths. African trans-equatorial paths, however, underperformed — possibly also due to limited monitoring time spend and the shrinking number of active MW broadcasters in that region. In contrast, the Argentine Beverage delivered consistently more results.



Unfortunately, for several years now, antenna deployment during the hunting season has been prohibited on the surrounding fields which results that the chances to end up in the "Winter Anomaly" is a real bugger, and this expedition clearly reflected that limitation. Signals frequently hovered just above the noise floor, with only brief enhancements lasting a minute or so. So you had to be lucky to be able to grab an ID in these cases. Nevertheless, it remains remarkable that even weak signals can still exhibit acceptable intelligibility under favourable noise conditions. Several stations, provided just sufficient audio for tentative or positive identification.



For the first time, a temporary FMDX.org remote server was brought online at the site. It utilised an oddly shaped antenna that had originally been intended as a ground-plane but proved usable as a receive antenna.



Medium-wave propagation showed gradual improvement, particularly on the Argentine Beverage, where signal levels increased in small but noticeable steps over the days.



The final day offered improved South American propagation. Signals from Argentina and Brazil were present across the band, generally weak but with occasional short-duration peaks — unfortunately often outside ID windows. As a result, many more stations were detected than ultimately logged, due to the absence of positive identification.



Notable catches with ID included R Atual, São Paulo, Brazil, on 1230 kHz. The station had changed its name from Boa Vontade to R Atual only one month earlier, and it had not previously been logged from this location under either identity.

Further First-logged stations were: Radio San Genaro, San Genaro Norte, Argentina, on 1550 kHz, Radio Durazno, Uruguay, on 1430 kHz



On 4 December, a strong candidate signal was detected that could only correspond to Universo 970, Paraguay. The measured carrier offset matched perfectly; however, no spoken ID was heard. This station has been logged 26 times in MWList worldwide during the current year, yet only three of those logs include a positive ID, underlining the difficulty of confirmation.



Dave, Jan, Aart, Leen, Cornel,

Guido, Stef and Frank.

We were pleased to welcome Stef as part of the team. He provided assistance in a wide range of practical tasks in the field, the kitchen, the stove,etc, and shared valuable knowledge. As a newcomer to the Jaguar SDR user group, he also benefited from extensive exchanges with experienced Jaguar users.



It was equally rewarding to observe Frank’s home-designed and home-built NAVTEX receiver in operation, demonstrating excellent performance in real-world conditions.



Leen caught some nice Fax pictures shown below.

Boston – 12750 kHz

Wiluna – 15615 kHz

On Friday, KNL-16 officially came to an end. The dismantling process — including the recovery and rolling in of several dozen reels of wire and coaxial cable — proceeded efficiently. All participants returned home safely. Several members left with storage media full of SDR recordings awaiting detailed post-expedition analysis.



While propagation conditions were occasionally uninspiring, the expedition nevertheless yielded a number of valuable catches. Moreover, it remains likely that additional weak or unidentified signals are still hidden within the recordings.



Many thanks to all participants whose efforts contributed to the success of this MW-DXpedition.

KNL-15 DXpedition (7-11 February 2025)

With some delay, here is the report from our latest DX-pedition to Knollehof in Veurne, Belgium.

We started on Friday the 7th. Weather was fine and putting up the antennas was going fine, also because we had an hour extra of daylight compared to last December.  All antennas were up and running on day one. BTW, Martin Hall's trick to use a 9V battery+ LED to measure continuity of the beverages was very helpful.

Continuity test of the Beverage

We had just like the previous edition a beverage to North-America (300°), a BoG to Africa (150°) a reversible 2 wire beverage to Japan/Argentina (45/225°) and Far East/Colombia (80/260°). Other antennas could be spotted like Jan's Vertical 9,- m, LZ1AQ, KAZ and Van Dijken LA1, Leen's Vertical 7,- m, T2FD for 13 MHz and inverted V for 9 MHz and higher and Frank Huyghe's Sony AN1.

The crew was exactly the same as in December.

Medium Wave conditions target seems to focus still more or less on South America. Far-East was almost completely dead and we heard also a few Africans but not the hoped South Africans stations. Signals were clearly better than the previous stay there but not yet as we would like to see it.

We were also suffering from QRM from PSU's and HDD's that we could reduce for some part but not efficient enough. Plans are made to pinpoint this in much more detail next time.

Attempting to reduce QRM from the ext HD by
covering it in Alu foil. It helped but not enough

The night of the 9th was focusing on Argentina and Brazil and the10th was the better one for North-America. Strange was that the 11th North America was also quite good on the ARG-antenna. Propagation will stay a mystery for ever I suppose.

But sometimes, DX signals haven't to be the most exotic to be interesting. Take for example this interesting announcement from VOCM seeking for a new Broadcast technician. Somebody here might be interested.

Guido Schotmans · VOCM Saint John's NL 590U 2025-02-11 02'02'17 KNL

A full MW-log report be extracted from https://dxing.fi/log/ by Logging in with your MWList credentials, selecting Listening date from 7 to 11 February and select BEL as logging country.

Our Knollehof DXped First logs for this edition.

[]

Receiving a 1 KW station from Taiwan : Tien Sheng Guangbo Diantai, AM 1215 kHz.

As you have noticed all in all conditions were far from optimal during the last edition of KNL-14. North America delivered only standard logs and mostly at low to mediocre strength. The number of South Americans was way lower than before, but while digging in the archived files we found a real gem on the Asian antenna. Several Taiwanese songs (as per Shazam/Flairmax) were popping up a few times on 1215 kHz raising question marks. Could this really be the listed 1 KW Taiwan station? Exchanging thoughts with Chris Kadlec on RealDX where more than encouraging. His advice to listen at xx:57 for ID’s did the trick. Yes indeed that was the one ! Incredible DX especially under these circumstances.

Find out more about Chris Kadlec Chinese AM Radio database here.

"Waves and Winds” - KNL-14 - The 14th Knollehof DXpedition Adventure" - 2-6 December 2024.

Last week, we were once again at our DX spot at Knollehof in Veurne for a five-day DXpedition.

In spring, there was some uncertainty about whether we would still be able to use the fields for setting up the long Beverage antennas, as the farmer was a bit uncooperative. Allegedly, we had not adhered to agreements, but it was all a misunderstanding.

Together with Hugo (our local DX-collegue), I launched a charm offensive to convince him. With considerable effort, we managed to restore trust. However, the farmer did set a clear condition: we could only use the fields after the end of the hunting season in December. This led to a change in the schedule: the DXpedition was moved to a midweek, from Monday, December 2, to Friday, December 6.

Fortunately, there were no floods in neighbouring municipalities or farmer protests blocking highways like last year.

Most of us arrived around noon. After setting up the shacks, we got to work outdoors, erecting the Beverage antennas. The morning rain had cleared, and our new participant, Cornel, already had experience setting up Beverage antennas elsewhere. We set up a North America beverage (300°, 300 m), a RevBev Japan/Argentina (45/225°, 400 m), and Africa BoG (150°, 300 m) antenna.

Preparing for the field work.

When looking carefully you can see the Alvear Tower
in Buenos Aires at the end of the antenna.

The Africa antenna quickly delivered a hit with a clear signal from Radio Nacional de São Tomé e Príncipe.



Guido Schotmans · R.Nacional De Sao Tome E Principe, Pinhe 945U 2024 - 12 - 02 20'18'58 KNL

However, the conditions were not in our favour for the rest of the trip. It seemed that all antennas were mostly only picking up European signals. A creative attempt to improve the conditions with a so-called "one-million dollar antenna" yielded little result. The team began to suspect that the radio gods were not smiling on us.

The one million Dollar conditions booster

On the second day, we set up the Far East/Colombia Beverage antenna (80/260°, 400 m). Jan had brought a whole arsenal of antennas: a vertical antenna (7 meters) with a balun, an AL1 loop antenna from Van Dijken Elektronica, and an LZ1AQ antenna. Additionally, a T2FD and a Sony AN1 were also spotted.

Cornel, also an avid Jaguar user on medium wave, also conducted other experiments with an RTL-SDR patch antenna for the L-band (1525–1600 MHz). The setup was improvised, using a garden chair, but the results were excellent. Even 10500 Bd data and 8400 Bd voice channels came through clearly. Software such as Jaero (aviation) and Scytale-C (maritime) was used.

Leen explored the fax frequencies, including the Pacific, Honolulu (11090 kHz), Wiluna (15615 kHz); Asia, JFX Kagoshima (16907.50 kHz), Tokyo JMH (7795 kHz), and Shanghai (16539 kHz). Even though the conditions were not special, it’s always better than being at home.

Shanghai 16539 kHz

Frank Huyghe focused his attention on Navtex and Fax projects that he built himself. If I heard correctly, I caught him exclaiming, "Murmansk Fax !"

Aart, Frank Thijs, and Guido doggedly persisted with MW-DX, but their determination yielded little. The anticipated conditions on medium wave completely failed to materialise. Moreover, we discovered a few days later that the North America antenna was performing very poorly. After inspecting various connections, we eventually found that the termination resistor was defective. The 1 kOhm potentiometer had a maximum value of only 170 ohms. In the future, we will replace it with a more robust fixed resistor.

The DX-gang : Frank H, Jan, Aart, Frank T, Leen, Guido and Cornel.

In between, we also went hunting for TII codes from the DAB+ transmitter in Oostduinkerke. Since DAB transmitters use a Single Frequency Network, you can only reliably determine the transmitted TII code near the transmitter itself.

The conditions remained lacklustre. Evidence of this was reflected in our condition barometer.

Conditions barometer in bad shape.

The DXpedition ended as it began: with typical winter weather. It was dry, but the strong winds made dismantling the antennas a challenge. Everyone worked together to wrap up safely. By around 12:00 local time, everything was packed up.

The 14th edition of the Knollehof DXpedition came with its own challenges and surprises but, as always, featured the indispensable radio experience.

Although the 14th Knollehof DXpedition did not experience the best conditions, the team once again brought out the best in themselves. The setbacks strengthened the collaboration and enthusiasm to keep experimenting. With a new participant like Cornel and the lessons learned, we are already looking forward to the 15th edition in February. Who knows, it might bring better radio conditions and more success.

Real Gem found in the KNL-13 files !

A real gem was found in the KNL-13 jaguar files by Marc Vissers.  We noticed already that on the 3^rd of February on 1210 kHz a signal that was surfacing occasionally bringing it just to minimal audio levels with religious content in Spanish, but it was hard to find any clear indication of which station it really was. The offset of 1209.9943 kHz made us dreaming that this could be the low power  250 Watts Radio El Libertador, Vergara, Uruguay. And YES !!! Marc found after a long intensive search an announcement at 0433 UTC as "Esta edición es una producción de Radio Transmundial". This is the overnight program that is carried by Radio El Libertador !

There are no other entries in MWList that this stations is logged in Europe before. Only Martin Hall from MWC logged it last year in Scotland. Also Jaguar’s Tomcat Nordic loglist doesn’t show it.

We also tried to verify that this station is really only 250 Watts searching the Unidad Reguladora de Servicios de Comunicaciones site (Uruguayan FCC equivalent) and and the Normativa y Avisos Legales del Uruguay and found this http://www.impo.com.uy/bases/resoluciones/276-1998/1

So it sounds like the power listed in the WRTH and MWList is correct.

Well done Marc !!!

KNL-13 DXpedition (1-5 February 2024)

Our journey for KNL-13 turned out to be surprisingly smooth, despite concerns about getting caught in the midst of farmer protests. The fields, unlike the previous November edition, were in excellent condition. We were blessed with favorable weather conditions initially, which unfortunately took a turn in the following days, becoming extremely windy.

The highlight of our expedition was the second night, perfect for South-American DX. It marked our first attempt at setting up a reversible beverage antenna pointing towards Argentina and Japan, reducing the length of coaxes. To our amazement, we picked up Japan's JOFR RKB Mainichi Hoso, Fukuoka on 1278 kHz with considerable strength, a rarity during this period of high solar activity. However, no other Japanese stations managed to make it to our extensive antenna farm.

As the days progressed, propagation conditions deteriorated, resulting in miserable conditions during the final night. We suspected the Japan wire might have been damaged, possibly due to the relentless wind. Upon rolling it up, we discovered a significant portion of wire was left in the field, necessitating a search afterward. It was also a surprise to notice that nothing was heard from the Far East and Central Asia.

The beverage antenna for Colombia/Far East faced challenges from local pulsing noise, and we struggled to identify the culprit. Despite these obstacles, our trip to the western corner of Belgium proved once again to be fascinating, yielding more than a handful of FIRST logs.

Antennas used : Rev-bev JPN/ARG 45/225°, rev-bev CLM/AUS 260/80°, bev NAm 300°, BOG AFR 150°, Sony AN1 (Frank), T2FD + INV-V 9MHz (Leen), 40m longwire (Ron), LZ1AQ loop + vertical + Mini Whip model Veron/VRZA (Jan).

FIRST logs noticed so far :

Protesting farmers put sign posts upside down	The Argentine/Japan RevBev Balun

Jaguars in action

T2FD catching Chile Fax transmission

Rolling in the beverage in windy conditions

Frank, Ron, Aart, Guido, Jan, Leen and Marc.

Happy Birthday Aart !
